Model
|
EC1200S
|
Inverter Type
|
Bidirectional Inverter
|
Output
|
AC Output X3
|
Rated Voltage
|
100-120vac/220-240Vac
|
|
Rated Power
|
1200W
|
|
Peak Power
|
2400W
|
|
Frequency
|
50/60HZ
|
USB Output
|
5V/1A
|
Type-c Output
|
5V/1A
|
Input
|
AC Input
|
100-120vac/220-240Vac 2.4A
|
Solar Panel
|
12V-30V 85W
|
Battery
|
Rated Capacity
|
1152WH
|
Rated Voltage
|
25.6V
|
Battery Cell Type
|
Lithium iron phosphate cylindrical type IFR 32140
|
Operating Temperature
|
0-40℃
|
Battery Cycle Life
|
3000times
|
Protection Function
|
Short circuit, overload, over temperature, over voltage, over current, under voltage etc,automatic release
|
Monitoring Paramenters
|
system voltage,cell voltage and temperature,Current,PCBA temperature
|
Certifications
|
CE,ROHS,UN38.3,MSDS,UL1642,IEC62619,IEC62133
|
General
|
Package
|
Wooden Case+Pearl Wool
|
Products Size
|
773*489*499mm
|
Package Size
|
843*559*569mm
|
Net Weight
|
31kgs
|
Gross Weight
|
34kgs
|
Qty/20ft
|
104pcs
|
Qty/40hq
|
254pcs
|
Accessory
|
AC charger cable *1,Instruction manual*1,Foldable trolley*1
|
Optional Accessories
|
Solar panel*1,Car charging cable*1,Solar charging cable *1,DC5521patch cord *1
|
Electric Grill(900w)
|
50mins
|
Ice Shaver(700w)
|
85mins
|
CPAP(Ac Outlet)
|
17Hrs
|
Laptop(Mackbook Pro13)
|
8 charges
|
Blender(500w)
|
2Hrs
|
Tv(60w)
|
12Hrs
|
