●IP65 enclosure for hybrid inverter
●Accept dual AC inputs,utility power and generator powe
●150%unbalanced load support
●Built-in WiFifor mobile monitoring(App is available)
●Enhance AC/Solar charger to 50A
●Wide batteryinput range
●Built-in communication port for BMS(RS485)
●Self-consumption and feed-back to the grid
●Programmable supply priority for PV,battery or Grid
●Programmable multiple operation modes:Grid-tie,off-grid and grid-tie with backup
●Lithium Iron Phosphate(LFP)cell
●Scalable Li-lon battery expansion
|
Model |
EJ-5000 |
EJ-5001 |
EJ-5002 |
EJ-5003 |
|
Capacity |
5.12KWh/5KW |
10.24KWh/5KW |
15.36KWh/5KW |
20.48KWh/5KW |
|
Standard discharge current |
50A |
|||
|
Max.discharge current |
100A |
|||
|
Working voltage range |
43.2-57.6VDC |
|||
|
Standard Voltage |
51.2VDC |
|||
|
Max.charging current |
50A |
|||
|
Max.charging voltage |
57.6V |
|||
|
Rated PV input voltage |
360VDC |
|||
|
MPPT tracking voltage range |
120V-450V |
|||
|
Max input voltage (VOC)at lowest temperature |
500V |
|||
|
Max input power |
6000W |
|||
|
Number of MPPT tracking paths |
1Path |
|||
|
DC input voltage range |
42-60VDC |
|||
|
Rated mains power input voltage |
220VAC/230VAC/240VAC |
|||
|
Grid power input voltage range |
170VAC-280VAC(UPSmode)/120VAC~280VAC(Invertermode) |
|||
|
Grid input frequency range |
45Hz~55Hz(50Hz):55Hz~65HZ(60Hz) |
|||
|
Inverter output efficiency |
94%(MAX) |
|||
|
Inverter output voltage |
220VAC+2%/230VAC+2%/240VAC+2%(Inverter mode) |
|||
|
Inverter output frequency |
50Hz+0.5or 60Hz+0.5(Inverter mode) |
|||
|
Inverter output waveform |
Pure sine wave |
|||
|
Grid output efficiency |
>99% |
|||
|
Max mains charging current |
60A |
|||
|
Max PV charging current |
100A |
|||
|
Max charging current(Grid+PV) |
100A |
|||
|
Optional mode |
Grid priority/PV priority/Battery priority |
|||
|
Warranty |
5~10Years |
|||
|
Communication |
Optional:RS485/RS232/CAN WiFi/4G/Bluetooth |
|||
