Model
|
EC3600
|
Inverter Type
|
Bidirectional Inverter
|
Output
|
AC Output X3
|
Rated Voltage
|
100-120vac/220-240Vac
|
|
Rated Power
|
3600W
|
|
Peak Power
|
7200W
|
|
Frequency
|
50/60HZ
|
USB Output
|
5V/1A
|
Type-c Output
|
5V/1A
|
Input
|
AC Input
|
100-120vac/220-240Vac 10A
|
Solar Panel
|
15V-100V 25A
|
Battery
|
Rated Capacity
|
2880WH
|
Rated Voltage
|
48V
|
Battery Cell Type
|
Lithium iron phosphate cylindrical type IFR 32140
|
Operating Temperature
|
0-40℃
|
Battery Cycle Life
|
3000times
|
Protection Function
|
Short circuit, overload, over temperature, over voltage, over current, under voltage etc,automatic release
|
Monitoring Paramenters
|
system voltage,cell voltage and temperature,Current,PCBA temperature
|
Certifications
|
CE,ROHS,UN38.3,MSDS,UL1642,IEC62619,IEC62133
|
General
|
Package
|
Wooden Case+Pearl Wool
|
Products Size
|
615*395*475mm
|
Package Size
|
685*465*544mm
|
Net Weight
|
38kgs
|
Gross Weight
|
41kgs
|
Trolley Weight
|
11kgs
|
Qty/20ft
|
162pcs
|
Qty/40hq
|
392pcs
|
Accessory
|
AC charger cable *1,Instruction manual*1,Foldable trolley*1
|
Optional Accessories
|
Solar panel*1,Car charging cable*1,Solar charging cable *1,DC5521patch cord *1
|
Projector 100w
|
26Hrs
|
Blender 300w
|
8Hrs
|
Electric grill 1500w
|
2.6Hrs
|
Coffee Maker 500w
|
4Hrs
|
Air Conditioner 8000w
|
3.2Hrs
|
Microwave 800w
|
1.5Hrs
|
TV 60W
|
37+Hrs
|
Refrigerator 150w
|
3Hrs
|
