Product Model
|
E5004
|
Product Specifications
|
384V100AH
|
Battery Pack Capacity
|
38.4KWh
|
Standard Discharge Current
|
50A~300A(Customized according to customer needs)
|
Maximum Discharge Current
|
50A~500A(Customized according to customer needs)
|
Operating Voltage Range
|
324-432VDC
|
Standard Voltage
|
384V
|
Maximum Charging Current
|
100A~500A(Customized according to customer needs)
|
Maximum Charging Voltage
|
81~864V
|
Recommended Discharge Depth
|
Number of cycles 3000-6000TIMES@DOD 80%/25 C/0.5C
|
Operating Humidity
|
65±20%RH
|
Operating Temperature
|
-10-+50℃
|
Working Altitude
|
≤2500m
|
Cooling Type
|
Natural cooling
|
Installation Type
|
Stacked installation
|
Protection Level
|
IP20
|
Maximum Number Of Parallel Connections
|
15PCS
|
Warranty
|
5~10 years
|
Communication Mode
|
Default:RS485/RS232/CAN Optional:WiFi/4G/Bluetooth
|
Product Certification
|
CE ROHS FCC UN38.3 MSDS
|
